OCR and voting disk storage configuration for normal redundancy

Last published : Jun 11, 2026
Figure: OCR and voting disk storage configuration for normal redundancy illustrates the OCR and voting disk storage options for normal redundancy.
Figure: OCR and voting disk storage configuration for normal redundancy
OCR and voting disk storage configuration for normal redundancy
The OCR and voting disk files exist on separate cluster file systems.
Configure the storage as follows:
  • Create separate filesystems for OCR and OCR mirror.
  • Create separate filesystems for a minimum of 3 voting disks for redundancy.
  • The option Normal Redundancy must be selected at the time of installing Oracle Clusterware/Grid Infrastructure.
    Note: It is recommended that you configure atleast resource dependency for high availability of the OCR and voting disk resources.
